Apple Patent Reimagines MacBook With Apple Pencil Replacing Function Row

Apple visualises a Pencil housed above the keyboard that could also be used for input.

By David Delima | Updated: 3 June 2022 19:18 IST

Apple Patent Reimagines MacBook With Apple Pencil Replacing Function Row

Photo Credit: Yankodesign/ Sarang Sheth

An 3D designer's impression of an Apple Pencil housed above the keyboard based on the patent

Highlights

Apple has filed a revamped patent to add Pencil support to MacBook
The Apple Pencil could be housed in place of the function key row
Apple first applied for the patent to add Pencil support in 2021

Apple has reportedly applied for a revamped patent that would support an Apple Pencil mounted above the MacBook keyboard. The claims include the ability to magnetically retain or secure the Pencil when it is placed the storage area and use the pencil as function keys while housed in the chassis. The patent, which the company first applied for last year, imagines the Pencil as a replacement for the function keys row. There's no word from Apple on plans to incorporate the technology in upcoming MacBook models.

According to a report by Patently Apple, the Cupertino giant has added 20 new patent claims to the invention, as part of continuation patent number 20220171474. The patent explains that the input tool could be stored in a recess of the keyboard housing or the chassis, and that the application is a continuation of Apple's 2020 patent application for a “Mountable tool computer input”.

Apple's patent application suggests the compant could use the Pencil as an input tool when it is housed in the chassis
Photo Credit: Patently Apple

With the newly filed patent continuation application, Apple has illustrated a system where the Apple Pencil can be stowed away in a retainer, or along the chassis of the MacBook. While the company's latest 14-inch and 16-inch MacBook Pro models got rid of the Touch Bar in favour of function keys, the application says that the retainer can support a high-end lighting system, to allow the Pencil to replace the function-key row on the MacBook.
